Bend angle: 87°
Diameter connection 1: 110/160 mm
Diameter connection 2: 110/160 mm
Length of connection 1: 150 mm
Length of connection 2: 160 mm
Wall thickness inner pipe: 2.7 mm
Working length connection 1: 150 mm
Working length connection 2: 105 mm
Colour: White
Dry (non-condensing): No
Material inner pipe: Plastic
Material outer pipe: Aluminium
Material sealing: Ethylene-propylene diene monomer rubber (EPDM)
Max. medium temperature (continuous): 120 °C
Negative (negative pressure): No
Number of lips: 2
Position of lips: Straight
Positive (overpressure): Yes
Production method for inner pipe: Other
Production method for outer pipe: Seamless weld (butt)
Quality class inner pipe: Polypropylene (PP)
RAL-number: 9016
Shape: Inspection piece, square
Surface protection outer pipe: Untreated
Surface treatment outer pipe: Other
Wet (condensing): Yes
With bottom support: No
With clamping strip: No
With inspection opening and cover: Yes
With lip ring: Yes
With measuring points: No
