Bend angle: 87°
Bend radius: 40 mm
Inner diameter, connection 1: 76 mm
Inner diameter, connection 2: 81 mm
Length: 415 mm
Length of connection 1: 290 mm
Length of connection 2: 125 mm
Outer diameter connection 1: 80 mm
Outer diameter connection 2: 85 mm
Wall thickness: 2 mm
Working length connection 1: 290 mm
Working length connection 2: 75 mm
Adjustable: No
Bend model: Smooth bend
Colour: White
Dry (non-condensing): No
Material: Plastic
Material quality: Polypropylene (PP)
Material sealing: Ethylene-propylene diene monomer rubber (EPDM)
Max. medium temperature (continuous): 120 °C
Negative (negative pressure): No
Number of lips: 2
Only suitable for air supply: No
Position of lips: Straight
Positive (overpressure): Yes
Production method: Seamless
RAL-number: 9016
Shape: Bend
Surface protection: Untreated
Surface treatment: Untreated
Wet (condensing): Yes
With clamping strip: No
With lip ring: No
With measuring connector: No
With pressure switch: No
